JET 30

JET 30

Inline polypropylene centrifugal fan

JET 30 Specifications (pdf)

The JET 30 from SEAT Ventilation is a polypropylene centrifugal fan suitable for the extraction of corrosive gases with a maximum air flow of 3500 m3 /h and a diameter of 250 mm in suction and discharge.

In direct drive the turbine is fixed directly on the motor shaft. It can be supplied with single-phase or three-phase motors with a frequency converter to meet the requirements of your installations.

For further information and advice on specific applications please contact our technical department.

Available in ATEX Zone 2 version only with three-phase motors.


TECHNICAL CHARACTERISTICS

  • Air flow: 900-3500 m3 /h
  • Total pressure: 150-800 Pa
  • Sound level (A): RPM 1150=77dB, RPM 1725-88dB
  • Aspiration: diameter 250 mm
  • Material : polypropylene
  • Training : direct
  • Engine power supply: single-phase 115/230V or three-phase 230/460V
  • Frequency : 50 Hz or 60 Hz with frequency converter
  • Temperature: 60°C

► Find the right product for your project even more easily, thanks to our online selection software:

ZEPHYR


SELECT POSITION (LG ONLY):

Choose the position


The JET range from SEAT Ventilation has centrifugal fans dedicated to in-line mounting. The JET motor is enclosed in a housing and is protected from the corrosive flow as well as the elements.

Their performances range from 200 to 3500 PT (pa) static pressure and from 80 to 1400 m³/h. The integrated waterproof cover and the disconnector constitute an excellent installation package.

With a vertical discharge, this fan is typically mounted on a roof or wall (vertical or horizontal mount). Application areas for JET fans are often swimming pools, water parks, municipal aquatic facilities, marine and saltwater environments, chemical/chlorine storage alleys, booster tank systems, closed tube slide ventilation systems, underground equipment/chemical vaults, fitness facilities, and more.

The JET range is manufactured from recyclable, UV-resistant polypropylene and complies with ISO 9001-2008 standards.

View as

No products found

Frequently Asked Questions

Corrosion resistant polypropylene fans

Which exhaust fan should I choose?

You can use our ZEPHYR online selection tool to help you choose your exhaust fan at: https://www.seat-selection.com/log_identifie.php?language=gb

The direction of rotation, why is it important?

Our centrifugal fans are made up of various components, including an impeller. Depending on your installation, this turbine will turn to the left or to the right.

That's why there are 2 different types of impeller: LG or RD.

An LG fan turns clockwise, with the volute outlet to the left.An RD fan turns counter-clockwise. The volute outlet is to the right.

Why is this important? If an LG turbine is used on an installation requiring an RD (or vice versa), the efficiency of your ventilation will be greatly reduced.

For more information, please contact our ventilation experts on 05.61.69.84.43 or by e-mail info@seat-ventilation.com

How long is the warranty?

Fans are warranted against defects in material and workmanship for two years from the original shipment date. Any unit or part found defective and reported within the warranty period will be replaced after inspection by SEAT VENTILATION, with transportation prepaid by the sender. Deterioration caused by wear and tear due to heat, abrasive action, chemicals, improper installation or use, or lack of normal maintenance do not constitute defects and are not covered by the warranty. Transportation to and from the factory for warranty repairs is not covered by the warranty and is the sole responsibility of the equipment owner.
The manufacturer shall not be liable for installation, removal, or reinstallation costs, or for any consequential damages resulting from failure to comply with the terms of any warranty.
